Spider Telescopic Lifting Crawler Crane Ladder

Spider Telescopic Lifting Crawler Crane Ladder

Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
  • Spider Telescopic Lifting Crawler Crane Ladder
Product Details:
Place of Origin: Shandong, China
Brand Name: OEM
Contact Now
Detailed Product Description
Condition: New Lift Drive / Actuation: Hydraulic
Table Size: CUSTOM Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert
Product Name: Self-propelled Curved Arm Lift Keywords: Hydraulic Vehicle-mounted Elevating Platform
Application: Widely Lift Drive: Hydraclic
Load Capacity: 250kg Lifting Height: 4-18 Meter
Lifting System: Hydraulic Lift Cylinders Operation Way: Platform Operate
After Warranty Service: Video Technical Support Platform Size: CUSTOM
Showroom Location: Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lift Mechanism: Screw Lift
Warranty: 2 Years Machinery Test Report: Provided
Video Outgoing-inspection: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: Pressure Vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine, PLC
Power: CUSTOM Min. Lifting Height: 1m, 2m, 3m
Overall Dimensions: CUSTOM Weight: 2000 Kg

Spider Telescopic Lifting Crawler Crane Ladder 0
Spider Telescopic Lifting Crawler Crane Ladder 2
Spider Telescopic Lifting Crawler Crane Ladder 4
Spider Telescopic Lifting Crawler Crane Ladder 6
Spider Telescopic Lifting Crawler Crane Ladder 8
Spider Telescopic Lifting Crawler Crane Ladder 10
Spider Telescopic Lifting Crawler Crane Ladder 12

We first consider the safety of use from the early stage of design

To ensure that you are foolproof during use
We've done a lot of security testing for this
Spider Telescopic Lifting Crawler Crane Ladder 14
Spider Telescopic Lifting Crawler Crane Ladder 16
Spider Telescopic Lifting Crawler Crane Ladder 18
Spider Telescopic Lifting Crawler Crane Ladder 20
Safety devices we have added for safe use
To protect your safety
Spider Telescopic Lifting Crawler Crane Ladder 22
Overload protection:
The hydraulic unit is equipped with an overload protection device. If overloaded, the hydraulic station will automatically release pressure and stop running.
Emergency stop:
In the event of an emergency, the elevator can be stopped immediately.
Emergency descent
There is an emergency lowering valve on each section of the pole. If there is a problem with the equipment, emergency lowering can be used.
Explosion-proof valve:
The hydraulic system is equipped with an explosion-proof valve to prevent the platform from suddenly falling when the oil pipe ruptures.
Safety sensor
When the platform is lowered, if it hits anything, it will stop to protect the cargo or operators.
Torque shaft
It adopts a torsion shaft design with good balance and comes with its own spring. When the ground is uneven, it will automatically level. After being powered on, it has its own electromagnetic brake.
We have 20 years of manufacturing experience in our factory, exporting our services to more than 50
countries and regions around the world, and OEM for many foreign brands. We always insist that
product quality is the lifeline of an enterprise and have been working hard for this
Spider Telescopic Lifting Crawler Crane Ladder 24
Security dual control


Dual control switch to avoid


accidental touch operation
Steel drag chain


More durable than plastic

products
Spider Telescopic Lifting Crawler Crane Ladder 26
Spider Telescopic Lifting Crawler Crane Ladder 28
Imported braking system
Braking system imported from Italy


ALKO imported from Germany
LCD control system
Touch control system

Smoother human-computer

interaction and customizable

multi-language system
Spider Telescopic Lifting Crawler Crane Ladder 30
Spider Telescopic Lifting Crawler Crane Ladder 32
Stable hydraulic system

Listed company hydraulic system

good quality

Durable and long-lasting
Foldable

Listed company hydraulic system

good quality

Durable and long-lasting
Spider Telescopic Lifting Crawler Crane Ladder 34
Spider Telescopic Lifting Crawler Crane Ladder 36
Convenient for work

Workbar with socket
Convenient to use electrical

tools for work
Model Number
dimension(mm)
lifting height(m)
working height(m)
platform size(mm)
Weight(ton)
loading capacity(kg)
Working radius(m)
THKB0.2-10
6645*2050
10
12
750*800
1.7
200
3
THKB0.2-12
6100*1700
12
14
750*800
1.8
200
3.5
THKB0.2-14
6500*1700
14
16
750*800
1.9
200
4
THKB0.3-16
6700*1700
16
18
1000*650
4.2
200
9.3
THKB0.4-18
6800*1700
18
20
1000*650
5.8
200
12
THKB0.4-20
7000*1700
20
22
1000*650
6.5
200
9.3
custom
custom
custom
custom
custom
custom
custom
custom
Our Factory
VR
Spider Telescopic Lifting Crawler Crane Ladder 38
Spider Telescopic Lifting Crawler Crane Ladder 40
Spider Telescopic Lifting Crawler Crane Ladder 42
Spider Telescopic Lifting Crawler Crane Ladder 44
Exhibition display
Spider Telescopic Lifting Crawler Crane Ladder 46
cooperative client
Spider Telescopic Lifting Crawler Crane Ladder 48
Spider Telescopic Lifting Crawler Crane Ladder 50

FAQ

Q1. What about the delivery time? Answer: It usually takes about 10 working days after we receive the deposit. Q2. What kind of payment do you support? Answer: T/T, L/C, West Union, Alibaba Trade Assurance. T/T is usually. Q3. How to proceed with an order for the lift? Answer: Firstly, tell us your requirements, if you can send a photo of where you will use the lift, it will be better. Secondly, we send you our suggestions and quote according to the practical. Q4. How to transfer the lift machine? Answer: It is usually shipped by sea. Plywood package and LCL in a 20' container. Q5. Is it OK to print my LOGO on the lift? Answer: Yes. Please inform us formally before our production and send us your high pixel LOGO. Q6. How can I get the after-sales service? Answer: Contact us if you have any questions or need professional support. We will try to solve your problem in 24 hours and arrange the delivery of spare parts in 48 hours. (Please make sure to communicate with me before paying directly, because the price in the title is just a deposit, not the full amount! !)
