Name: Small Aerial Mobile Electric Lift Table Scissor Lift Wheel Work Platform
Brand: Shandong Haokun Heavy Industry Machinery Group Co., Ltd.
Availability: InStock

Home Products Three-wheeled vehicle

Small Aerial Mobile Electric Lift Table Scissor Lift Wheel Work Platform

Product Details:

Place of Origin:	Shandong, China
Brand Name:	HaoKun

Contact Now

Detailed Product Description

Condition:	New	Weight:	30000 Kg
Power Souce:	Electric	Table Size:	On-demand Customization
Applicable Industries:	Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Retail, Food Shop, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company	Wheelbase:	2500mm
Ground Clearance :	0.3m	Gradeability:	0.25
Lifting/lowering Speed:	150/120sec	Max. Platform Occupancy:	4 Pers
Material:	Other	Lift Mechanism:	Telescoping Lift
Keywords:	Hydraulic Vehicle-mounted Elevating Platform	Application:	Widely
Lift Drive:	Hydraclic	Load Capacity:	500KG
Lifting Height:	6-14M	Lifting System:	Hydraulic Lift Cylinders
Control:	Control Panel + Remote Controller	Scissor:	Single Scissor
Product Name:	Hydraulic Platform Lift

30 km long endurance

Professional engineer team which can supply 3D proposal drawing and design according to customer request.

Operation manual and video training how to use themachine.

Engineers available to service machi nery overseas.

12 months warranty period and we will provide theconsumable parts at cost price after the warranty period.

high maneuverability

Heavy duty electric tricycle

Customized,thickened material,

smooth walking,quick reaction,

maximum speed of 30km/h

Model 500-12 heavy rims tyre

Durable,non-slip,wear resistance

for a variety of working environ-

ment

Long battery life

Add six phase motor,strong

bearing capacity,strong power,

low energy consumption.Model

150 battery:super power life

Selected raw materials

The frame structure is more

stable

Improved large straight arm

bracket

of excellent workmanship

Reasonable and fixed tubing line

routing

Resistance to high pressure and

high temperature

Innovative Design

Customized special shaft

pin,refused to break the

denitration,New

type of shaft pin without back wire

Simpler maintenance

Support pin quenching and

tempering treatment

Better design for maintenance

Install maintenance support to

make maintenance work safer

Model	Platform size	Max. platform height	Rated capacity	Overall size
MP-0.5-4	2010*830	4 M	500 KG	330012001270
MP-0.5-6	2010*830	6 M	500 KG	330012001370
MP-0.5-6.8	2010*830	6.8M	500 KG	330012001370
MP-0.5-8	2010*830	8 M	500 KG	330012001470
MP-0.5-9	2010*830	9 M	500 KG	330012001590
MP-0.5-10	2010*1130	10M	500 KG	353015001650
MP-0.5-11	2010*1130	11M	300 KG	353015001780
MP-0.5-11.5	2010*1130	11.5 M	300 KG	353015001780
MP-0.5-12	2500*1210	12 M	500 KG	400016501980

_{Shandong Haokun Heavy Machinery Group Co. LTD., the largest lifting platform manufacturer in north China, has 16 years of AWP industry experience. The company has a technical team, R & D team, assembly team, domestic trade department, overseas export department, administration department, management team and more than 200 employees.has a workshop in Jiyang District, covering an area of 23,000 square meters, with the most advanced laser cutting machine, bending equipment, drilling machine, spot welding machine, assembly machine sand blasting machine, etc}

_{Our main products are self-propelled scissor lifts, crawler scissor lifts, loading and unloading platforms, simple arm lifts and aluminum lifts. Over the years, the products are exported to North America, South America, Western Europe, Northern Europe, Southeast Asia and other countries and regions, enjoying a high reputation around the world.}

Factory real shot

FAQ

1. What 's our delivery time?
Normally we have inventory of the standard products, if not, we need 7-10 days to produce the standard products and 10-15 days for
the customized products.

2. What's our guarantee?
We have one year guarantee period for you, during this time, we can provide you with non-human damaged parts for free. And we 24h
provide online service.

3.Do we accept customization?
Sure, we can customize a product according to your requirements. And we can do OEM&ODM for you.

4. Why should I buy from you not from other suppliers?
We are professional in producing the hydraulic lift equipment for logistics, warehouse, factory and construction using. We are
alarge-scale lifting platform manufacturing enterprise integrating R&D, production and sales.

5. What's our MOQ (minimum order quantity)?
It is one unit. But we have a good discount if you order more.
